Smartec CLD132 Technology Data
The CLD132 measurement system is designed for monitoring products in brewing, dairy and beverage production, CIP control, phase separation in pipelines, acid/base concentration control and bottle‑wash monitoring. It features a stainless‑steel housing, a PEEK‑based hygienic sensor, self‑monitoring functions and resistance to polarization and fouling.
The device provides multiple communication options (HART handheld terminal, PROFIBUS PA/DP, PC software), a large two‑line display, optional temperature current output, and a range of accessories such as extended cables, VBM junction boxes and installation kits. It operates over a wide temperature range (‑35 °C to +250 °C) and offers fast temperature response (t90 < 5 s). This manual is written in Chinese.
Covers: Technical Data · Measurement Principle · System Design · Specifications · Outputs · Power Supply and Wiring
Latest Smartec manuals
Smartec CLD132 Technology Data
Datasheet 20 pages · 408 KB · ZHThe Smartec CLD132 is a stainless‑steel, inductive conductivity and concentration measurement system for food‑industry processes, offering electrode‑free…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Smartec manuals
What communication options are available for the CLD132?
The device can be operated with a keypad, a HART® handheld terminal, PROFIBUS PA/DP, or PC software (Commu win II).
What power supply voltages can the CLD132 use?
It can be powered from 100 V, 115 V or 230 V AC (±10 %/‑15 %, 48‑62 Hz) or from a 24 V AC/DC source.
