Featured SFGW manuals
Fuguang Watt SFGW Series Temperature Transmitter Manual
The SFGW series rail‑mounted temperature transmitter converts thermocouple or RTD signals into a linear 4‑20 mA DC output, offering isolation between input, output, and power to improve system reliability. The device includes features such as cold‑junction compensation, high insulation resistance, and a compact mounting design.
The manual lists technical parameters, wiring diagrams, physical dimensions (24 × 98 × 100 mm), installation procedures for the support‑type rail (TS35), and maintenance recommendations. Warranty information and optional load‑capacity specifications are also covered. This manual is written in Chinese.
Covers: Introduction · Technical Specifications · Electrical Characteristics · Physical Dimensions · Installation Guidelines · Wiring Diagram
Latest SFGW manuals
Fuguang Watt SFGW Series Temperature Transmitter Manual
User Manual 26 pages · 570 KB · ZHThe manual provides specifications, installation instructions, and maintenance guidelines for the Fuguang Watt SFGW series rail‑mounted temperature transmitter.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SFGW manuals
What type of input signals does the transmitter accept?
It accepts either thermocouple or RTD (thermoresistance) signals.
From: Fuguang Watt SFGW Series Temperature Transmitter Manual
What is the standard output current range?
The standard output current range is 4‑20 mA.
From: Fuguang Watt SFGW Series Temperature Transmitter Manual
