Featured RINCK-A manuals
RINCK A 410 Uninterruptible Power Supply Datasheet
The RINCK A 410 is an uninterruptible 24 V DC power supply designed for continuous operation. It features a maintenance‑free internal battery (1.3 Ah) and an optional external battery up to 10 Ah. The unit switches automatically to battery power when the mains voltage falls below 19.5 V and resumes operation as soon as mains power returns.
Technical data include an input voltage range of 85‑250 V AC (90‑300 V DC), output of 24 V DC at up to 1.5 A continuous (2 A peak), efficiency up to 90 %, and compliance with EN 60950, EN 50178 and other standards. The enclosure is steel sheet (TS35) weighing 2000 g with dimensions 130 × 100 × 102 mm. This manual is written in German.
Covers: Anschlussklemmen · Technische Daten · Netz Eingang · Stromaufnahme · Meldungen · Gewicht
RINCK A400 Technology Data Sheet
The A400 series from RINCK Electronic provides an uninterrupted power supply solution with a 230 V line input and a 24 V battery output. It includes connection examples for accessory modules and a range of display units such as the PMS511, PMS518, and PMS528.
Additional monitoring devices are available, including limit switches for output and battery voltage, as well as a battery‑rest‑charge current monitor. The system can be equipped with an LCD display showing voltage, current and power, and optional galvanically isolated RS‑232/RS‑485 interfaces. This manual is written in German.
Covers: Circuit Example · Connection Example · Display Options · Monitoring Devices · Limit Switches · Battery Rest‑Charge Monitoring
Latest RINCK-A manuals
RINCK A 410 Uninterruptible Power Supply Datasheet
Datasheet 1 pages · 39 KB · DEThe RINCK A 410 provides an uninterruptible 24 V DC power supply with a 1.3 Ah internal battery and accepts 85‑250 V AC input.
RINCK A400 Technology Data Sheet
Datasheet 1 pages · 116 KB · DETechnical data sheet for the RINCK A400 UPS series, detailing display options, monitoring devices, and voltage/current specifications.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in RINCK-A manuals
What is the input voltage range?
The unit accepts 85‑250 V AC or 90‑300 V DC input.
What is the capacity of the internal battery?
The internal battery is rated at 1.3 Ah.
