Rheonik RHM 06 Mass Flowmeter Technology Data
The RHM 06 is a mass flowmeter capable of measuring up to 25 kg/min (55 Ib/min) at temperatures above 350 °C and pressures up to 430 bar. It uses Rheonik's patented Omega tube and torsion‑rod swinger design, delivering 0.10 % accuracy and better than 0.05 % repeatability without pressure‑induced errors.
The document details three construction types (parallel, serial, and seal‑less welded), a range of flange and connection options, material choices for wetted parts, and the various ATEX, CSA, PED and custody‑transfer approvals. Electrical connections are IP65 rated, with a maximum cable length of 100 m (330 ft) standard and 200 m with factory approval.
Covers: General Overview · Applications · Features · Performance · General Outline Dimensions · General Specifications
Latest Rheonik-RHM06 manuals
Rheonik RHM 06 Mass Flowmeter Technology Data
Datasheet 7 pages · 235 KB · ENThe Rheonik RHM 06 technology data provides specifications, dimensions, approvals, and connection options for this mass flowmeter.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Rheonik-RHM06 manuals
What pressure rating does the standard version of the RHM 06 have?
The standard version is rated for 380 bar at 120 °C.
