Featured RG-H manuals
Huayi Power RG-H Capacitor Bridge Tester User Manual
The RG‑H Capacitor Bridge Tester, developed by Huayi Power, is designed for on‑site measurement of high‑voltage parallel capacitor banks and reactors in substations. It offers four‑wire measurement, a large LCD with touch keys, USB data transfer, and automatic compensation for accurate results.
The manual covers product introduction, safety precautions, detailed wiring for Y, Δ, and Yn connections, panel description, step‑by‑step measurement procedures, menu functions, USB driver installation, and data export to Word reports. It also lists technical specifications and measurement error ranges. This manual is written in Chinese.
Covers: Product Introduction · Operation and Use · Instrument Panel Description · Wiring Method · Interpretation of Measurement Results · Menu Functions
Latest RG-H manuals
Huayi Power RG-H Capacitor Bridge Tester User Manual
User Manual 20 pages · 622 KB · ZHThe Huayi Power RG‑H Capacitor Bridge Tester User Manual provides operation, wiring, and measurement instructions for high‑voltage capacitor and inductor…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in RG-H manuals
How many measurement steps are required for a three‑phase test?
The measurement process must be performed three times, one for each phase.
How do I install the USB driver for the tester?
Connect the instrument, power it on, and follow the prompts to install the USB driver from the supplied CD.
