Featured Raymarine manuals
Raymarine C120 Color Multi-Function Digital Radar Technical Specification
The Raymarine C120 series is a color multi‑function digital radar that uses a high‑resolution 12.1" LCD display with an effective 180 mm screen diameter. It offers intuitive human‑machine interaction, customizable menus, and supports multiple languages, making it suitable for small commercial vessels, workboats, and yachts.
Four antenna configurations (5S, 7S, 9S, 11S) provide options ranging from 4 ft to 6 ft. The radar operates with a power supply of 10.7‑32 VDC, consumes between 108 W and 191 W, and meets CFR46 waterproof standards. Interfaces include DSH, NMEA 0183, SeaTalk, SeaTalk2/NMEA 2000, and a chart‑card slot. This manual is written in Chinese.
Covers: General Overview · Performance Parameters · Antenna Options · Power Consumption · Dimensions and Weight · Interfaces
Latest Raymarine manuals
Raymarine C120 Color Multi-Function Digital Radar Technical Specification
Product Leaflet 2 pages · 163 KB · ZHThe Raymarine C120 color multi‑function digital radar technical specification outlines performance, dimensions, power, and interface details for the C120…
Questions answered in Raymarine manuals
What is the power consumption range for the C120 models?
Power consumption varies from about 108 W to roughly 191 W depending on the configuration.
From: Raymarine C120 Color Multi-Function Digital Radar Technical Specification
How many antenna sizes are available for the C120 series?
Four antenna sizes are offered: 5S (4 ft), 7S (6 ft), 9S (4 ft), and 11S (6 ft).
From: Raymarine C120 Color Multi-Function Digital Radar Technical Specification
