Featured PS3100 manuals
Goyen Controls PS3100 Water Pressure Sensor Manual
This manual provides full guidance for installing and configuring the PS3100 water pressure sensor, including mechanical mounting, sealing, and wiring. It also explains how to use the SmartCom software for data acquisition, calibration and alarm functions.
Technical details such as measurement range, accuracy, memory capacity, power consumption and communication interfaces (RS232, SDI‑12, NODE‑M) are listed, along with optional accessories and part numbers for different installation scenarios. This manual is written in Chinese.
Covers: Features · Specifications · Installation · Calibration · Communication Interfaces · Data Storage
Greenspan PS3100 Water Level Pressure Sensor Technical Guide
The Greenspan PS3100 water level pressure sensor uses a robust ceramic capacitive element to deliver high linearity and temperature‑compensated measurements across multiple selectable ranges. It is housed in a corrosion‑resistant phenolic resin case with optional stainless‑steel construction for harsh environments.
The guide details sensor installation, wiring options (RS232 or SDI‑12 via adapter), software configuration with SmartCom, and provides full technical specifications such as measurement ranges, accuracy, power consumption and memory capacity. This manual is written in Chinese.
Covers: Product Introduction · Product Advantages · Installation and Wiring · Software Usage · Technical Specifications · Optional Accessories
Latest PS3100 manuals
Goyen Controls PS3100 Water Pressure Sensor Manual
User Manual 3 pages · 690 KB · ZHThe PS3100 manual describes installation, operation, communication and specifications of the water pressure sensor.
Greenspan PS3100 Water Level Pressure Sensor Technical Guide
User Manual 6 pages · 884 KB · ZHTechnical guide for the Greenspan PS3100 water level pressure sensor, covering features, installation, software use and specifications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in PS3100 manuals
What temperature range can the sensor operate in?
It operates from 0 °C up to 50 °C.
What output interfaces does the PS3100 sensor support?
The sensor can output data via RS232 directly or via SDI‑12 when an SDI‑12 adapter (model 7SDI‑1000) is installed.
From: Greenspan PS3100 Water Level Pressure Sensor Technical Guide
How much data can the PS3100 store internally?
It has 2 Mb of memory, capable of storing about 250 000 readings when sampled every five minutes.
From: Greenspan PS3100 Water Level Pressure Sensor Technical Guide
