Featured PKE manuals
PKE Series Electric Parameter Transmitter User Manual
The PKE series electric parameter transmitter converts measured signals into linearly proportional DC current or voltage outputs with isolation. It uses advanced surface‑mount technology for long‑term stability, high anti‑interference ability and precision, and is suitable for industrial automation, factory automation and environmental monitoring systems.
The manual lists technical specifications such as input ranges, response time, output types, environmental limits, isolation voltage, dimensions and mounting options, and includes wiring diagrams, terminal definitions and warranty information. This manual is written in Chinese.
Covers: Product Overview · Technical Specifications · Model Configuration · Terminal Definitions and Dimensions · Wiring Diagram · Warranty
Latest PKE manuals
PKE Series Electric Parameter Transmitter User Manual
User Manual 1 pages · 51 KB · ZHThe PKE series electric parameter transmitter manual provides product overview, specifications, wiring and installation instructions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in PKE manuals
What input signals does the PKE series transmitter accept?
It can accept either a current signal from 0 to 10 A or a voltage signal from 0 to 500 V.
How can the device be mounted?
The transmitter can be mounted on a 35 mm DIN rail or fixed with M3 screws.
