Key facts
- Manuals
- 5
- Languages
- ZH
- Last added
- 2012-03-29
Featured PIEXUS manuals
PEZUS AVM1000 Installation Manual
This manual explains how to safely install and operate the PEZUS AVM1000 programmable multimedia central control system. It includes important safety precautions such as proper grounding, avoiding moisture, and ensuring adequate ventilation before powering the unit.
The guide details hardware connections – infrared ports, RS232/485 interfaces, network RJ45 port, audio/video matrix, VGA and serial ports – and describes how to use the accompanying network control software for device monitoring, user management, and remote control of connected equipment. This manual is written in Chinese.
Covers: 注意事项 · 硬件连接 · 红外发射口 · 网络接口 · 音视频输入输出 · 9针串口接口
Latest PIEXUS manuals
PIEXUS AV-VC Volume control system installation Manual
This document is the installation and user manual for the AV-VC volume control system, which describes the function description, characteristic parameters, and panel instructions of the mixing module.
PEZUS AVM1000 Installation Manual
Installation Guide 19 pages · 1.1 MB · ZHThe PEZUS AVM1000 installation manual provides safety guidelines, hardware connections, communication protocol, and software usage instructions.
PIEXUS Can programming In Center control system AVM3000 installation Manual
PIEXUS Can programming In Center control system AVM2000 installation Manual
PIEXUS pl-m300pvl installation Manual
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in PIEXUS manuals
How many infrared ports does the AVM1000 have and what are their default assignments?
The AVM1000 provides eight infrared ports. By default IR1 controls a DVD player, IR2 a VCR, IR3 a display, IR4 a card slot/camera, IR5 a reserved/wired port, IR6 a projector, and IR7/IR8 are reserved.
What voltage is required for the AVM1000 power supply?
The unit requires a 220 V AC power supply at 50 Hz.
