Featured PEPPERL manuals
Pepperl+Fuchs CJ1-12GK-N-5M Capacitor Sensor User Manual
This manual describes the CJ1-12GK-N-5M capacitor sensor, a standard‑series 1 mm non‑flush mounting sensor designed for use in hazardous zones. It includes technical data, certification information (ATEX 1G, 2G, 1D) and compliance with IEC and EN standards.
The document covers installation, adjustment, maintenance, and special conditions such as mechanical protection and static electricity handling. It also specifies limits for ambient temperature, cable length, and provides guidance on safe connection to intrinsically safe equipment. This manual is written in Chinese.
Covers: General Description · ATEX 1G Certification · ATEX 2G Certification · ATEX 1D Certification · Installation and Adjustment · Maintenance
Latest PEPPERL manuals
Pepperl+Fuchs CJ1-12GK-N-5M Capacitor Sensor User Manual
User Manual 3 pages · 182 KB · ZHThe Pepperl+Fuchs CJ1-12GK-N-5M capacitor sensor manual provides safety, installation, and operation instructions for hazardous area use.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in PEPPERL manuals
What is the maximum ambient temperature the sensor can operate in?
The sensor can be used up to an ambient temperature of 60 °C.
From: Pepperl+Fuchs CJ1-12GK-N-5M Capacitor Sensor User Manual
Is repair of the sensor allowed?
No, the sensor must not be repaired or modified.
From: Pepperl+Fuchs CJ1-12GK-N-5M Capacitor Sensor User Manual
