Key facts
- Manuals
- 2
- Languages
- EN · ZH
- Last added
- 2012-03-12
Featured OEM manuals
OEM ITX-945GC3B N330 Motherboard User Manual
The OEM ITX-945GC3B N330 motherboard is built with an on‑board Intel Atom N330 CPU and supports DDR2 memory up to 2 GB in a single‑channel configuration. It includes a range of interfaces such as IDE, PCI‑E network, SATA, USB 2.0, PS/2, and an on‑board HD‑AUDIO sound card.
The manual provides detailed instructions for safe hardware installation, BIOS configuration, power management settings, and driver installation. It also includes safety warnings, connector diagrams, and troubleshooting tips for common issues.
Covers: About the Product · Features · System Processor · System Memory · System BIOS · Interface of Peripheral Equipment
Beijing Maichuang Tongyuan Blood Oxygen Module BTN604 User Manual
The BTN604 is a compact, high‑reliability blood‑oxygen (SpO₂) and pulse‑rate monitoring module designed for use with adult, infant and newborn patients. It operates at 3.3 V, supports RS‑232 serial communication, and is compatible with BCI‑type probes.
The manual covers product features, safety warnings, electrical specifications, pin‑out diagrams, serial‑port protocol (4800 baud, 8‑N‑1), installation procedures, verification using a blood‑oxygen simulator, and warranty/maintenance instructions. This manual is written in Chinese.
Covers: Product Description and Design Application · Main Features · Safety Guidelines · Product Performance Specifications · Pin and Header Configuration · Serial Port Protocol
Latest OEM manuals
OEM ITX-945GC3B N330 Motherboard User Manual
User Manual 38 pages · 846 KB · ENUser manual for the OEM ITX-945GC3B N330 motherboard covering specifications, installation, BIOS setup, and troubleshooting.
Beijing Maichuang Tongyuan Blood Oxygen Module BTN604 User Manual
User Manual 9 pages · 142 KB · ZHThe BTN604 blood oxygen module manual provides product description, safety guidelines, specifications, connection diagrams, installation steps, and…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in OEM manuals
What CPU is integrated in the OEM ITX-945GC3B N330 motherboard?
The motherboard has an on‑board Intel Atom N330 CPU.
What is the maximum amount of memory the motherboard can support?
The board supports up to 2 GB of DDR2 memory.
What is the recommended working voltage for the BTN604 module?
The module operates at 3.3 V ± 0.17 V DC.
From: Beijing Maichuang Tongyuan Blood Oxygen Module BTN604 User Manual
What is the serial communication baud rate used by the BTN604?
The serial port uses a baud rate of 4800 bps with 8‑data bits, 1 stop bit and parity.
From: Beijing Maichuang Tongyuan Blood Oxygen Module BTN604 User Manual
