Featured NT manuals
NT TR3001 User Manual
The NTTR3001 is a low‑power 315 MHz wireless transceiver module that supports both OOK and ASK modulation. It operates from 2.7 V to 3.5 V and offers fast mode switching with low standby current.
The manual lists the module’s electrical parameters, pin functions, and mode transition timings, helping users integrate the device into their designs. This manual is written in Chinese.
Covers: Performance Parameters · Pin Definitions · Mode Description
Latest NT manuals
NT TR3001 User Manual
User Manual 2 pages · 352 KB · ZHThe NT TR3001 manual provides specifications, pin definitions, and operating modes for the low‑voltage 315 MHz OOK/ASK wireless transceiver module.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in NT manuals
What is the operating frequency of the NTTR3001 module?
The module operates at 315 MHz.
From: NT TR3001 User Manual
What are the transmission rates for OOK and ASK modes?
OOK mode transmits at 19.2 kbps and ASK mode at 115.2 kbps.
From: NT TR3001 User Manual
