Featured NDT manuals
Newcom CV08041JST/R Optical Audio Unit User Manual
The CV08041JST/R is an optical audio and Ethernet transmission unit that provides 8 channels of forward audio, 4 telephone voice channels and 1 Ethernet link over single‑mode fiber. It uses a dedicated ASIC and high‑speed DSP to deliver loss‑less, uncompressed 24‑bit audio up to 20 kHz and supports standard RJ‑45 10/100 Base‑T Ethernet.
The manual includes an overview of technical specifications, detailed installation and panel descriptions, wiring diagrams, typical applications, and service warranty information. Safety warnings address high‑voltage power and laser eye protection. This manual is written in Chinese.
Covers: Overview · Technical Specifications · Installation and Panel Description · Wiring and Connection Guidelines · Typical Applications · Service and Warranty
Jiangsu Newcom CA201JMT/R Video Optical Transceiver User Manual
The CA201JMT/R video optical transceiver provides bidirectional audio, telephone and Ethernet transmission over multimode fiber up to 2 km. It uses a dedicated ASIC and high‑speed DSP for loss‑less, high‑quality signal transport and is built with industrial‑grade components for reliable operation in harsh environments.
The manual includes an overview of technical specifications, detailed installation steps, panel descriptions, wiring diagrams, configuration settings, typical applications and warranty information. Safety warnings and power requirements are also provided. This manual is written in Chinese.
Covers: Overview · Technical Specifications · Power and Environmental Requirements · Installation and Panel Description · Wiring and Connection Diagrams · Settings and Application
NDT CV4501ST/R Optical Video User Manual
This manual describes the CV4501ST/R optical video transmitter, its features, and the required power and environmental conditions. It includes detailed wiring diagrams for video, Ethernet, RS‑422, and fiber‑optic interfaces.
Installation steps cover unpacking, checking accessories, mounting a 19‑inch 1U rack unit, and connecting power, video BNC, RJ45, and fiber ports. Operation guidance explains indicator LEDs, typical use cases, and maintenance recommendations. This manual is written in Chinese.
Covers: Overview · Installation · Wiring and Interfaces · Operation · Appendix
Newcom BCV8000ST/R Video Optical Transceiver User Manual
The BCV8000ST/R is an 8‑channel forward video optical transceiver that converts analog or digital video sources to high‑quality, lossless transmission over fiber. It supports PAL, NTSC, SECAM formats and uses a single‑mode fiber bus for distances up to 25 km.
The manual covers unpacking, panel layout, power connection, switch and jumper settings, and typical application examples. Safety notes warn that the optical output is a laser and must not be viewed directly, and that the unit requires a 220 V AC supply to be installed by qualified personnel. This manual is written in Chinese.
Covers: Overview · Technical Specifications · Power and Environmental Requirements · Installation and Panel Description · Switch and Jumper Settings · Typical Applications
Latest NDT manuals
NDT BCV 22111 JST/R video Optical Manual
Newcom CV08041JST/R Optical Audio Unit User Manual
User Manual 13 pages · 1.3 MB · ZHUser manual for the Newcom CV08041JST/R optical audio unit, covering specifications, installation, wiring and service information.
Jiangsu Newcom CA201JMT/R Video Optical Transceiver User Manual
User Manual 11 pages · 1.1 MB · ZHUser manual for the CA201JMT/R video optical transceiver, covering specifications, installation, wiring and operation.
NDT CV4501ST/R Optical Video User Manual
User Manual 12 pages · 993 KB · ZHThe NDT CV4501ST/R user manual provides installation, wiring, and operation instructions for the optical video transmitter.
Newcom BCV8000ST/R Video Optical Transceiver User Manual
User Manual 10 pages · 647 KB · ZHThe Newcom BCV8000ST/R manual provides installation, operation, and technical specifications for the 8‑channel video optical transceiver.
CZ Newcom CA04011JST/R Audio Optical User Manual
User Manual 12 pages · 1.3 MB · ZHThis manual provides installation, wiring and configuration instructions for the CA04011JST/R audio optical device.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in NDT manuals
What is the maximum transmission distance of the CV08041JST/R?
The unit can transmit over single‑mode fiber for up to 30 km.
What power input does the device require?
It operates from an AC supply of 165 V to 265 V and consumes about 15 W.
What is the maximum transmission distance of the CA201JMT/R?
The device can transmit over multimode fiber up to 0‑2 km.
From: Jiangsu Newcom CA201JMT/R Video Optical Transceiver User Manual
Which fiber connector type does the CA201JMT/R use?
It uses an FC/PC multimode duplex connector.
From: Jiangsu Newcom CA201JMT/R Video Optical Transceiver User Manual
What power supply does the CV4501ST/R require?
It requires an AC input of 165‑263 V and consumes about 15 W.
What are the environmental limits for operating the device?
The unit works from –30 °C to +70 °C, with humidity between 0 % and 95 % non‑condensing.
