Featured NATION manuals
National Instruments NI 9853 User Manual
This manual describes the safe operation of the NI 9853 high‑speed CAN module, including Class I Division 2, Group A‑D, and ATEX Zone 2 compliance. It outlines required safety precautions, protection device installation, and the software needed to use the module.
The document details the module’s pin assignments, wiring requirements, CAN bus topology, termination recommendations, and power specifications for CAN0 (internally powered) and CAN1 (+8 V to +25 V external). Contact information for National Instruments support offices worldwide is also provided. This manual is written in Japanese.
Covers: Operation Procedure · Safety Guidelines · Power Requirements · Pin Assignment · CAN Bus Topology and Termination · Wiring Instructions
Latest NATION manuals
National Instruments NI 9853 User Manual
User Manual 27 pages · 513 KB · JAThe National Instruments NI‑9853 User Manual provides safety guidelines, installation, wiring, and configuration instructions for the 2‑port high‑speed CAN…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in NATION manuals
What power does the CAN0 port require?
The CAN0 port is internally powered and does not need an external power source.
