Featured MINI-ARRAY manuals
Mini-Array MAC-1 Light Curtain System User Manual
The Mini-Array measurement light curtain system (MAC series) is designed for online dimension and shape measurement, part counting, and similar applications. A typical system includes a MAC-1 controller, two light curtains (emitter and receiver pairs) and the required cabling. Beam spacing can be 0.38 in (9.7 mm) or 0.75 in (19.05 mm) and curtain height ranges from 6 in to 4 ft.
The MAC-1 controller provides programmable scan analysis modes, two configurable outputs, and RS‑232/RS‑485 communication for PC or PLC integration. Software running on Windows or OS/2 allows parameter file (PSF) creation, alignment analysis, and self‑diagnostics. Scan time per step is 55 µs, enabling high‑resolution or high‑speed operation depending on the selected beam spacing. This manual is written in Chinese.
Covers: Product Description · Scan Analysis Modes · Output Settings · Scan Modes · Installation and Alignment · Software Installation
Latest MINI-ARRAY manuals
Mini-Array MAC-1 Light Curtain System User Manual
User Manual 33 pages · 1.9 MB · ZHThe Mini-Array MAC-1 user manual describes installation, configuration, scanning modes, output settings, and communication for the measurement light curtain…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in MINI-ARRAY manuals
What beam spacings can be selected for the light curtain?
Two beam spacings are available: 0.38 in (9.7 mm) and 0.75 in (19.05 mm).
What is the scan time per step for the MAC-1 controller?
Each scan step takes 55 µs.
