Featured MESSOTRON-Serie manuals
MESSOTRON DPL Inductive Rod Displacement Sensor Product Data Sheet
The MESSOTRON DPL series provides inductive rod displacement sensors for hydraulic and pneumatic applications, rated for pressures up to 200 bar. Various models (e.g., DPL 150Q, DPL 150R, DPL 150AX) offer different nominal travel ranges, mounting lengths, and weights to suit a wide range of installations.
Key performance figures include a carrier frequency of 10 kHz (optional 5 kHz), linearity error up to +0.596 % of travel, temperature compensation of ±0.049 % per 10 K, and an IP65 protection rating. The sensors operate from –40 °C to +80 °C and meet DIN 40050 standards for environmental sealing. This manual is written in German.
Covers: Product Description · Nominal Travel Range · Working Stroke · Mounting Length · Weight · Pressure Rating
Latest MESSOTRON-Serie manuals
MESSOTRON DPL Inductive Rod Displacement Sensor Product Data Sheet
Product Leaflet 1 pages · 29 KB · DETechnical data sheet for MESSOTRON DPL inductive rod displacement sensors, covering dimensions, ranges, and performance specs.
Questions answered in MESSOTRON-Serie manuals
What is the maximum operating pressure for the DPL sensors?
The sensors are rated for a maximum operating pressure of 200 bar, with a test pressure of 250 bar.
From: MESSOTRON DPL Inductive Rod Displacement Sensor Product Data Sheet
What temperature range can the DPL sensors operate in?
They can operate from –40 °C up to +80 °C.
From: MESSOTRON DPL Inductive Rod Displacement Sensor Product Data Sheet
