Featured measurement manuals

Measurement Specialties HTG3500 Series Relative Humidity and Temperature Module Datasheet

Datasheet 10 pages · 387 KB · EN

The HTG3500 Series are plug‑and‑play humidity and temperature transducers designed for OEM applications that require reliable, accurate measurements. They feature a rugged MEAS‑France humidity sensor, linear voltage output for humidity and a direct NTC output for temperature, and are optimized for low power consumption.

The modules support 3.3 V or 5 V supply options, operate over a wide temperature range, and include mechanical features such as screw‑mountable or PTFE‑membrane housings. They are qualified for harsh environments, offering protection against EMC, reverse polarity, and a variety of chemicals.

Covers: Description · Features · Performance Specifications · Electrical Characteristics · Temperature Characteristics · Mechanical and Connecting Characteristics

Measurement Specialties EPL Series Pressure Sensor Product Leaflet

Product Leaflet 5 pages · 121 KB · ZH

The EPL Series is a surface‑mount stainless‑steel pressure sensor offered by Measurement Specialties. It supports multiple pressure ranges from 0.35 bar (5 psi) up to 350 bar (5 000 psi) and can be installed easily using adhesive or resin.

The leaflet lists technical data such as resonant frequency (40 kHz to 350 kHz), temperature compensation range (‑40 °C to 90 °C), supply voltage (10 VDC) and typical output (125 mV). Options for different pressure ranges, compensation modules, and connector types are also provided, along with ordering codes and contact information for global sales offices. This manual is written in Chinese.

Covers: Product Description · Technical Specifications · Options and Accessories · Ordering Information · Contact Details

MEAS Sensor Application Reference Manual

Application Note 40 pages · 6.8 MB · ZH

This manual provides an overview of MEAS, a U.S. sensor manufacturer, and outlines its eight major sensor product families, including force, acceleration, pressure, position, magnetoresistive, tilt, humidity, temperature, and piezoelectric film sensors. It highlights MEAS’s global presence, certifications, and OEM customization capabilities.

The document details application examples across many sectors such as industrial machinery, medical devices, commercial building HVAC, home appliances, automotive and transportation, and consumer electronics. Each sensor type is described with typical use‑cases, performance highlights, and available form factors. This manual is written in Chinese.

Covers: MEAS Overview · Industrial Solutions · Sensor Solutions · Force Sensors · Acceleration Sensors · Pressure Sensors

Latest measurement manuals

• Measurement Specialties HTG3500 Series Relative Humidity and Temperature Module Datasheet

  Datasheet 10 pages · 387 KB · EN

  The HTG3500 Series module from Measurement Specialties provides plug‑and‑play relative humidity and temperature sensing with linear voltage and NTC outputs.

• Measurement Specialties EPL Series Pressure Sensor Product Leaflet

  Product Leaflet 5 pages · 121 KB · ZH

  The Measurement Specialties EPL Series pressure sensor product leaflet provides specifications, range options, and ordering information for the…

• measurement P900 series super metal strain pressure sensor Manual

• MEASUREMENT COMPUTING PCM-DAS08 Analog/Digital Inputs USER S MANUAL Manual

• measurement ATA-2001 LVDT amplifier Manual

• MEASUREMENT MSP-300 Stainless Steel Isolated Pressure Transducer Manual

• MEAS Sensor Application Reference Manual

  Application Note 40 pages · 6.8 MB · ZH

  The MEAS Sensor Application Reference Manual describes the various MEAS sensor families, their specifications, and typical industrial, medical, and consumer…
