Featured KSN manuals
KSN Series Intelligence Counter Manual
The manual describes the KSN series intelligence counter, highlighting its ability to process signals with high speed (up to 10 kHz) and a wide measurement range (0.0001‑45.000). It details various input modes, external control functions, and data logging capabilities, including printing and communication options.
Technical specifications such as power supply options (220 VAC, 24 VDC, 12 VDC), dimensions for different models, and supported communication interfaces (RS232, RS485, RS422) are listed, along with guidance on interference protection and environmental operating limits. This manual is written in Japanese.
Covers: Overview · Model Specifications · Technical Specifications · Functions and Parameters · Communication Interfaces · Printing Interface
Latest KSN manuals
KSN Series Intelligence Counter Manual
User Manual 38 pages · 487 KB · JAThe KSN Series Intelligence Counter manual provides an overview of features, specifications, communication interfaces, and operation instructions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in KSN manuals
What is the maximum measurement frequency of the counter?
The maximum measurement frequency is 10 kHz.
What are the dimensions of model A?
Model A measures 160 mm wide, 80 mm high, and 123 mm long.
