Featured KINAX manuals
KINAX WT 707 Angular Position Transmitter Product Leaflet
The KINAX WT 707 is a ruggedized angular‑position transmitter that outputs a load‑independent DC current proportional to the measured shaft angle. It offers selectable measuring ranges, direction of rotation, and optional intrinsic‑safety protection for hazardous areas.
The document contains technical specifications such as measuring range, output current options, power‑supply requirements, accuracy, temperature rating, housing protection (IP66), and weight. It also details mounting configurations, explosion‑protection certifications, and ordering codes for various versions and gear ratios.
Covers: Application · Features / Benefits · Technical Data · Mounting Options · Power Supply · Accuracy and Error Limits
Latest KINAX manuals
KINAX WT 707 Angular Position Transmitter Product Leaflet
Product Leaflet 12 pages · 322 KB · ENThe KINAX WT 707 transmitter converts shaft angular position to a load‑independent DC signal and provides technical data, mounting options, and…
Questions answered in KINAX manuals
What measuring range does the WT 707 cover?
The WT 707 can measure angles from 0 ° up to 270 °, with selectable ranges such as 0…5°, 0…10°, 0…30°, 0…60°, 0…90°, 0…180° and 0…270°.
From: KINAX WT 707 Angular Position Transmitter Product Leaflet
Which power‑supply voltages are supported?
The standard version operates from 12 V to 33 V, while the Ex version is limited to 12 V to 30 V.
From: KINAX WT 707 Angular Position Transmitter Product Leaflet
