Featured KCWV manuals
Kingcera KCWV Series SMD Power Inductor Datasheet
The KCWV series SMD power inductors are designed for high‑frequency use, offering excellent Q values and thermal stability. They are intended for use in modems, mobile phones, cordless telephones, GPS, xDSL filters, wireless communications equipment, networking systems, and computer peripherals.
Four size codes are available—3216, 3225, 4532, and 5750—each offered in Taping (T) or Bulk (B) packages. Detailed electrical specifications such as inductance, DC resistance, Q factor, and self‑resonant frequency are provided for each variant.
Covers: Features · Applications · Available Types · Dimensions · Identification · Electrical Specifications
Latest KCWV manuals
Kingcera KCWV Series SMD Power Inductor Datasheet
Datasheet 5 pages · 58 KB · ENThe Kingcera KCWV series SMD power inductors are high‑frequency components with various sizes and specifications for telecom and networking applications.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in KCWV manuals
What applications are the KCWV inductors suitable for?
They are used in modems, mobile phones, cordless telephones, GPS, xDSL filters, wireless communications equipment, networking systems, and computer products and peripherals.
What size codes are available in the KCWV series?
The series includes four size codes: 3216, 3225, 4532, and 5750.
