Key facts
- Manuals
- 3
- Languages
- JA · EN
- Last added
- 2012-03-14
Featured IEC manuals
IEC User Manual
The manual walks users through the four main steps for using the IEC system: initial registration, contract submission, order processing, and final reporting. Each step includes detailed screen actions, required fields, and cautions.
Additional sections provide frequently used reference tables, safety notices, and instructions for batch processing and printing of documents. This manual is written in Japanese.
Covers: 第一歩 登穫 IEC · 第二歩 · 第三歩 · 第四歩 · 附氷1 常用査銘 · 附氷2 注意事項
Siemens 1LE1 Motor Dimensional Drawings
This document provides detailed dimensional drawings for the Siemens New Generation 1LE1 aluminum series motors. It includes frame size ranges from 100 L to 160 L, pole configurations, and construction types such as IM B3, IM B5, and IM V1.
Flange dimensions, hole patterns, and extension details are listed, with references to the relevant DIN EN 50347 standards. The drawings also specify the length to the tip of the fan cover and other critical mechanical parameters needed for installation and integration.
Covers: Dimensional drawings · Types of construction · Flange dimensions · Frame size specifications · Dimension designation · Flange types
IEC Second edition 1998-02 Sound systems for emergency purposes Manual
This IEC standard specifies the technical requirements, performance criteria, and testing methods for sound systems used in emergency situations. It covers system operation, signal characteristics, and environmental conditions to ensure reliable audible warnings.
The document includes definitions, general system requirements, and detailed annexes describing attention signal levels, measurement procedures, and evaluation criteria. It references related IEC standards and provides normative and informative guidance for designers and installers.
Covers: Scope · Reference Documents · Definitions · General System Requirements · Attention Signal Characteristics · Measurement of Speech Intelligibility
Latest IEC manuals
IEC User Manual
User Manual 16 pages · 1.8 MB · JAUser manual describing how to register, submit contracts and manage orders on the IEC platform.
Siemens 1LE1 Motor Dimensional Drawings
Product Leaflet 9 pages · 1.8 MB · ENDimensional drawings and flange specifications for Siemens 1LE1 aluminum series motors, covering frame sizes 100 to 160.
IEC Second edition 1998-02 Sound systems for emergency purposes Manual
Other 24 pages · 200 KB · ENIEC 60849 defines requirements and measurement methods for emergency sound systems.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in IEC manuals
How do I submit a contract on the IEC platform?
Select the “合同等名” option, follow the prompts to fill in the required fields, and click “提交” to complete the submission.
From: IEC User Manual
What frame sizes are covered by the 1LE1 series?
The 1LE1 aluminum series covers frame sizes from 100 L to 160 L.
Where can I find the flange dimensions for these motors?
Flange dimensions are listed on page 1/98 of the document.
