Featured HDS-N manuals
Lilliput HDS-N Series Handheld Digital Storage Oscilloscope User Manual
This manual provides comprehensive guidance for the Lilliput HDS‑N series handheld digital storage oscilloscope, including the HDS1022M‑N, HDS2062M‑N and HDS3102M‑N models. It covers product certification, safety information, setup, basic and advanced measurement functions, and troubleshooting.
The document also contains detailed technical specifications, battery handling instructions, and maintenance procedures to ensure reliable performance in the field. This manual is written in Chinese.
Covers: Product Certificate · Safety Information · General Features · Oscilloscope Connections · Initial Use · Multimeter Use
Latest HDS-N manuals
Lilliput HDS-N Series Handheld Digital Storage Oscilloscope User Manual
User Manual 88 pages · 1.2 MB · ZHUser manual for Lilliput HDS‑N handheld digital storage oscilloscope covering safety, operation, specifications and maintenance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in HDS-N manuals
What must be done after a temperature change before taking measurements?
Open the system function menu and execute the “self‑calibration” program.
From: Lilliput HDS-N Series Handheld Digital Storage Oscilloscope User Manual
