Greenspan models by category
Featured Greenspan manuals
GREENSPAN 300 Series Sensor Accessories Technical Manual
The GREENSPAN 300 series includes a range of intelligent water‑quality sensors such as PS310, OFRP300, D0300, CTD350, and CS305. Each sensor integrates measurement, data processing, storage and power functions in a rugged, standalone unit suitable for harsh environments.
The system uses the SMARTCOM software on Windows for configuration, data management and graphical display via AQUAGRAPH. Optional accessories include adapters (SA100, MA300), data recorders (SL300) and long‑life batteries, all designed for reliable operation with RS‑232 communication and IP65 protection.
Covers: Product Introduction · Smart Sensor Types · Technical Specifications · Adapter Interface · Data Recorder · Battery
GREENSPAN PS1000 Water Level Pressure Sensor User Manual
The GREENSPAN PS1000 is a ceramic‑capacitive water level pressure sensor designed for harsh environments. It offers selectable measurement ranges, 4‑20 mA or 0‑2.5 VDC analog output, and optional SDI‑12 output via an adapter. The sensor housing is made of corrosion‑resistant polyoxymethylene resin, with optional stainless‑steel construction for high‑temperature and high‑pressure applications.
The manual covers product features, installation options (including protective port sleeves and 1/4" BSP fittings), wiring diagrams, software configuration using the PS7000UTILITY program, and detailed technical specifications such as accuracy, temperature stability, power requirements, and cable length options. This manual is written in Chinese.
Covers: Product Introduction · Product Advantages · Installation and Wiring · Software Usage · Technical Specifications · Application Areas
Greenspan PS100 Pressure Sensor User Manual
This manual describes the PS100 pressure sensor, including its design features, sealing technology, and suitability for harsh environments. It covers the sensor's construction, sealing methods, and options for mounting on pipes or tanks.
The document also provides detailed electrical specifications, wiring diagrams, output signal information, and performance parameters such as accuracy, temperature stability, and drift. Installation procedures and recommended connection methods are included. This manual is written in Chinese.
Covers: Technical Specifications · Installation Guidelines · Electrical Connections · Performance Parameters · Mounting and Sealing · Output Signal
Latest Greenspan manuals
GREENSPAN 300 Series Sensor Accessories Technical Manual
Datasheet 5 pages · 474 KB · ENTechnical manual for GREENSPAN 300 series intelligent water‑quality sensors and their accessories, including specifications and installation details.
GREENSPAN PS1000 Water Level Pressure Sensor User Manual
User Manual 5 pages · 994 KB · ZHThe GREENSPAN PS1000 water level pressure sensor manual provides product overview, installation, wiring, software setup, and technical specifications.
Greenspan PS100 Pressure Sensor User Manual
User Manual 4 pages · 250 KB · ZHThe Greenspan PS100 pressure sensor user manual provides specifications, installation instructions, and performance data for the sensor.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Greenspan manuals
What is the power supply voltage range for the SL300 data recorder?
The SL300 operates from an 8 V to 15 V supply.
From: GREENSPAN 300 Series Sensor Accessories Technical Manual
How is the sensor protected against moisture?
It includes a fully sealed vent system (CVS) that isolates the vent tube from ambient moisture, preventing condensation inside the cable.
From: GREENSPAN PS1000 Water Level Pressure Sensor User Manual
What measurement ranges are available for the PS1000?
Standard ranges are 2.5, 5, 10, 20, 40, 75, and 100 m, with custom ranges available on request.
From: GREENSPAN PS1000 Water Level Pressure Sensor User Manual
What supply voltage does the PS100 require?
It operates from a DC supply of 8 V to 30 V.
What is the operating temperature range of the PS100?
The sensor can operate from –3 °C up to 60 °C.
