Featured FS8-WJ manuals
FS8-WJ Splash-proof Flow Switch User Manual
This manual describes the FS8‑WJ splash‑proof flow switch, a compact sensor designed to detect flow interruptions or low flow in water pipelines. It explains the sensor’s principle of operation, which uses a paddle and a micro‑valve to generate an ON/OFF output signal when flow changes.
The document includes installation guidelines, electrical connection details, dimensional data, and performance specifications such as maximum operating pressure, temperature range, and supported voltage levels. Safety notes and part numbers for replacement components are also provided. This manual is written in Chinese.
Covers: Purpose · Specifications · Installation · Operation · Electrical Connections · Dimensions
Latest FS8-WJ manuals
FS8-WJ Splash-proof Flow Switch User Manual
User Manual 1 pages · 24 KB · ZHThe FS8-WJ splash‑proof flow switch manual provides installation, operation, and specification details for the device.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in FS8-WJ manuals
What is the output signal of the FS8‑WJ flow switch?
The switch provides an ON/OFF output signal using a 5‑pole‑double‑throw (5PDT) contact.
Which voltage levels can the flow switch be powered with?
It can operate with 115VAC, 230VAC, 115VDC, or 230VDC.
