Featured ENG manuals
Eurotherm 2408/2404 PID Controllers Installation and Operation Handbook
The Eurotherm 2408 and 2404 PID controllers are high‑stability temperature and process controllers with modular hardware that accepts up to three plug‑in I/O modules and two interface modules. The handbook provides detailed guidance for installing the controllers in DIN panels, connecting power and signal wiring, and achieving IP65 sealing.
The manual is organized into chapters on Installation, Operation, Access Levels, Tuning, Programmer Operation, Configuration, and User Calibration, followed by appendices covering ordering codes, safety and EMC information, technical specifications, load‑current monitoring, PROFIBUS communications and RoHS compliance.
Covers: Installation · Operation · Access Levels · Tuning · Programmer Operation · Configuration
Latest ENG manuals
Eurotherm 2408/2404 PID Controllers Installation and Operation Handbook
User Manual 142 pages · 2.8 MB · ENInstallation and operation handbook for Eurotherm 2408 and 2404 PID controllers, covering setup, wiring, tuning, configuration and safety.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ENG manuals
How many digital inputs does the controller have?
The controller provides two digital inputs and an optional alarm relay.
From: Eurotherm 2408/2404 PID Controllers Installation and Operation Handbook
What wire size and torque should be used for terminal connections?
Use wire sizes from 0.5 to 1.5 mm² (16‑22 AWG) and tighten the terminals to a torque of 0.4 Nm.
From: Eurotherm 2408/2404 PID Controllers Installation and Operation Handbook
