Key facts
- Manuals
- 4
- Languages
- EN
- Last added
- 2012-08-03
Featured Eclipse manuals
Digital Horizon Solutions Eclipse 700 Service Manual
The Eclipse 700 Service Manual provides detailed information for technicians on configuring and maintaining the controller. It includes sections on jumper and DIP‑switch settings for RS‑232/RS‑485 ports, wiring requirements, and a comprehensive list of technical specifications for the MUX‑8 multiplexer module.
Additional chapters describe the various modules that can be attached to the Eclipse 700 system, such as Dual Door, Input Control, Output Control, Memory Expansion, and isolated multiplexers, along with required reference documents and environmental guidelines.
Covers: Jumper and Switch Usage · Technical Specifications - MUX-8 · Dual Door Module (AP-DDM) · Input Control Module (AP-ICM) · Output Control Module (AP-OCM) · Memory Expansion (SPM-MEM)
Latest Eclipse manuals
ECLIPSE ECT-2 ECT-4 Installation Operation Manual
This is an instruction manual for the installation and operation of the ECT-2 and ECT-4 corona discharge ozone generators
ECLIPSE - Contents Engineers Standard Case Kit handbook
The document is a list of tools, including different types and sizes of screwdrivers, pliers, spanners, cutters, etc. These tools have different functions and characteristics, and can be used for various works and tasks.
Eclipse Reference Manual
Digital Horizon Solutions Eclipse 700 Service Manual
Service Manual 240 pages · 8.1 MB · ENService manual for the Eclipse 700 controller covering installation, jumper settings, and technical specifications.
Which document do I need?
Service Manual
Disassembly, diagnostics and part numbers, for repair.
Questions answered in Eclipse manuals
What is the default baud rate when all jumpers are OFF?
When all four selection jumpers are OFF, the default baud rate is 300 bps.
Which ports support RS‑232 communication?
Port 1 can be configured for RS‑232; all other ports are RS‑485 only.
