Mornsun D_T-1W Series DC-DC Module Power Supply Manual

The D_T-1W series from Mornsun provides 1 W isolated DC‑DC conversion with fixed input voltage, dual isolated non‑regulated outputs, and up to 80 % efficiency. The modules are compact SMD packages, weigh 2.1 g, and meet RoHS requirements. They are designed for board‑level distributed power systems that need isolation from the input source, such as digital circuits, low‑frequency analog circuits, and IGBT driver circuits.

The manual includes product specifications, insulation characteristics, recommended application circuits, load requirements, and mechanical dimensions. It also gives usage notes such as minimum load conditions, protection recommendations, and PCB layout suggestions to ensure reliable operation. This manual is written in Chinese.

Covers: Product Features · Model Table · General Characteristics · Insulation Characteristics · Application Range · Product Selection
