Featured DYB-ZAG manuals
Dihui DYB-ZAG Pressure Transmitter User Manual
This manual describes the DYB‑ZAG intelligent pressure transmitter designed for industrial process pressure control across various sectors such as aerospace, petrochemical, medical, food, marine, and power generation. It highlights features like laser‑adjustable temperature compensation, imported diffusion silicon pressure sensor, strong overload and corrosion resistance, and a high‑contrast LCD display.
The document lists the main technical parameters, including output type, supply voltage, accuracy, temperature ranges, response time, and load capacity. It also provides detailed installation steps, wiring diagrams (including explosion‑proof connections), and safety precautions to ensure correct and reliable operation. This manual is written in Chinese.
Covers: Purpose · Features · Technical Specifications · Dimensions · Installation · Selection
Latest DYB-ZAG manuals
Dihui DYB-ZAG Pressure Transmitter User Manual
User Manual 1 pages · 1.3 MB · ZHThe Dihui DYB-ZAG pressure transmitter user manual provides specifications, installation, wiring, and safety instructions for industrial process pressure…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in DYB-ZAG manuals
What supply voltage does the DYB‑ZAG pressure transmitter require?
It requires a +24 VDC power supply.
Can the zero point be adjusted on the transmitter?
Yes, the zero point can be adjusted arbitrarily within the measurement range.
