Featured DA-2000 manuals
Datalink DA-2000 E1/V.35/RS232 Protocol Converter User Manual
This manual describes safety precautions and general usage for the DA-2000 protocol conversion equipment. Users should keep the device away from water, avoid tying or covering power cables, ensure all connections are secure, and clean the unit with a soft cloth. In case of water ingress, physical damage, abnormal operation, or unusual odors, power must be disconnected and the company contacted.
The document also details the device’s technical parameters, interface definitions, switch settings, operating environment, dimensions, and typical application scenarios. It explains how to configure E1, V.35, and RS232 interfaces, select clock modes, and adjust impedance and power settings for reliable data transmission. This manual is written in Chinese.
Covers: Safety Instructions · Technical Parameters · Interface Definition · Switch Settings · Clock Mode Configuration · Operating Environment
DATALINK DA-2000 E1/V.35/RS232 Protocol Converter User Manual
The DA-2000 protocol conversion equipment is designed to translate E1 signals into V.35 or RS232 asynchronous data interfaces. Safety instructions advise keeping the device away from water, avoiding cable damage, and contacting the company if the unit shows signs of malfunction.
Technical specifications cover interface rates, impedance settings, power requirements, operating temperature ranges, and physical dimensions. The manual also details front‑panel indicator meanings, switch functions, clock mode settings, and typical application scenarios. This manual is written in Chinese.
Covers: Safety Instructions · Technical Parameters · Interface Definition · Operating Environment · Physical Dimensions · Indicator Light Meaning
Latest DA-2000 manuals
Datalink DA-2000 E1/V.35/RS232 Protocol Converter User Manual
User Manual 15 pages · 462 KB · ZHThe Datalink DA-2000 E1/V.35/RS232 protocol converter user manual provides safety instructions, installation, configuration, and technical specifications.
DATALINK DA-2000 E1/V.35/RS232 Protocol Converter User Manual
User Manual 15 pages · 456 KB · ZHThe DATALINK DA-2000 converts E1 signals to V.35 or RS232 interfaces and includes safety guidelines, specifications, and configuration instructions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in DA-2000 manuals
What is the maximum data rate supported by the RS232 interface?
The RS232 interface supports a maximum asynchronous rate of 115200 bit/s (e.g., 9.6 K, 19.2 K).
From: Datalink DA-2000 E1/V.35/RS232 Protocol Converter User Manual
What power supply options are available for the DA‑2000?
The device can be powered from AC 220‑240 V or from DC -48 V (acceptable range -36 V to -72 V).
From: DATALINK DA-2000 E1/V.35/RS232 Protocol Converter User Manual
What are the operating temperature limits of the device?
It operates between 0 °C and 50 °C.
From: DATALINK DA-2000 E1/V.35/RS232 Protocol Converter User Manual
