Featured CIPCI-8 manuals
CIPCI CIPCI-8 Power Supply Controller User Manual
The CIPCI-8 is an eight‑channel high‑current power supply controller designed to work with a main control unit. Each channel can handle up to 10 A and a maximum load of 2200 W, giving a total capacity of 8000 W. The controller provides relay outputs for lighting, motorized screens, curtains and other accessories.
The manual explains the connection diagram, relay assignment, command codes for opening and closing relays, and serial communication settings (1200 bps, 8‑N‑1). It also includes hardware wiring details for connecting the controller to a Crestron host and examples of command strings for turning lamps on and off. This manual is written in Chinese.
Covers: Introduction · Connection Diagram · Relay Assignment · Command Codes · Serial Communication Settings · Hardware Connections
Latest CIPCI-8 manuals
CIPCI CIPCI-8 Power Supply Controller User Manual
User Manual 5 pages · 61 KB · ZHUser manual for the CIPCI-8 eight‑channel high‑current power supply controller, describing wiring, commands and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in CIPCI-8 manuals
How many channels does the CIPCI-8 controller have?
It has eight independent relay channels.
What is the maximum current each relay can handle?
Each relay can handle up to 10 A of current.
