Key facts
- Manuals
- 4
- Languages
- ZH
- Last added
- 2012-01-16
Featured BSD manuals
BSD DC power supply automate P1L-BSD-6200L P1L-BSD-6600L P1L-BSD-6600LF P1L-BSD-8000L P1L-BSD-8200L P1L-BSD-8800L P1L-BSD-8800LF electric Screwdriver Manual
This manual provides safety instructions, operating procedures, and maintenance guidelines for the Kilews P1L‑BSD series electric screwdrivers (models 6200L, 6600L, 6600LF, 8000L, 8200L, 8800L, 8800LF). It covers proper use, torque adjustment, grounding checks, and recommended service intervals.
The document also lists technical specifications, standard accessories, and a detailed parts list for each model, helping users select the correct bits, springs, and other components. Safety warnings emphasize keeping the work area clean, avoiding moisture, and never exceeding the torque scale of 8. This manual is written in Chinese.
Covers: Safety Instructions · Operating Precautions · Grounding Check · Technical Parameters · Torque Adjustment · Standard Accessories
QiliSu P1L-BSD-1000 / P1L-BSD-1200 Electric Screwdriver Service Manual
This manual explains the safety precautions that must be observed before using the electric screwdrivers, including keeping the work area clean, avoiding moisture, and disconnecting power before any maintenance. It also describes the correct way to install bits, adjust torque, and operate the forward/reverse switch.
Technical specifications such as input voltage, rated power, torque range, weight and dimensions are listed, followed by detailed instructions for torque adjustment, recommended usage limits, and a complete parts list for service and repair. This manual is written in Chinese.
Covers: Safety Guidelines · Operation Procedure · Technical Specifications · Torque Adjustment · Parts List · Maintenance and Service
Kilews P1L-BSD-3000/3200/3300 Electric Screwdriver Operation Manual
This manual provides safety warnings, operating procedures, torque‑adjustment instructions and maintenance guidelines for the Kilews P1L‑BSD‑3000, P1L‑BSD‑3200 and P1L‑BSD‑3300 electric screwdrivers. It also lists the standard accessories and part numbers for each model.
Technical specifications, grounding instructions and a detailed parts list are included to help users set up the tool correctly and keep it in good working condition. This manual is written in Chinese.
Covers: Safety Instructions · Operation Procedure · Torque Adjustment · Grounding Instructions · Technical Specifications · Standard Accessories
BSD electric Screwdriver AC power supply automate P1L-TKS-1500LS P1L-TKS-2500LS P1L-TKS-3500LS P1L-TKS-4500LS P1L-TKS-2500LSF Manual
This manual provides safety precautions, proper usage instructions, and maintenance procedures for the Qili Speed P1L‑TKS‑4500LS series electric screwdrivers. It covers preparation before operation, correct handling of the tool, and guidelines for safe work environments.
Technical specifications, torque adjustment methods, grounding verification, and a complete parts list are included to help users achieve reliable performance and extend the tool’s service life. This manual is written in Chinese.
Covers: Safety Precautions · Grounding Instructions · Technical Specifications · Torque Adjustment · Operation Procedure · Maintenance and Service
Latest BSD manuals
BSD DC power supply automate P1L-BSD-6200L P1L-BSD-6600L P1L-BSD-6600LF P1L-BSD-8000L P1L-BSD-8200L P1L-BSD-8800L P1L-BSD-8800LF electric Screwdriver Manual
User Manual 14 pages · 2.1 MB · ZHOperation and safety guide for Kilews P1L-BSD electric screwdriver series.
QiliSu P1L-BSD-1000 / P1L-BSD-1200 Electric Screwdriver Service Manual
Service Manual 8 pages · 1.6 MB · ZHThe service manual provides safety guidelines, operation steps, technical specs, torque adjustment and maintenance procedures for the QiliSu P1L‑BSD‑1000…
Kilews P1L-BSD-3000/3200/3300 Electric Screwdriver Operation Manual
User Manual 8 pages · 1.4 MB · ZHOperation manual for Kilews P1L‑BSD‑3000/3200/3300 electric screwdrivers with safety, usage and maintenance instructions.
BSD electric Screwdriver AC power supply automate P1L-TKS-1500LS P1L-TKS-2500LS P1L-TKS-3500LS P1L-TKS-4500LS P1L-TKS-2500LSF Manual
User Manual 10 pages · 1.5 MB · ZHOperation, safety, torque adjustment and maintenance guide for the Qili Speed P1L‑TKS‑4500LS electric screwdriver series.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Service Manual
Disassembly, diagnostics and part numbers, for repair.
Questions answered in BSD manuals
How long should the screwdriver be used each day?
The recommended maximum daily use is 8 hours.
What is the maximum torque setting allowed?
Do not adjust the torque beyond the scale marked “8”.
How many self‑tapping screws can be driven per hour?
Up to 900 screws per hour (Ø2.6 mm × 5 mm) on steel/iron plates.
From: QiliSu P1L-BSD-1000 / P1L-BSD-1200 Electric Screwdriver Service Manual
What is the recommended maximum daily usage time?
The screwdriver should not be used for more than 8 hours per day.
From: QiliSu P1L-BSD-1000 / P1L-BSD-1200 Electric Screwdriver Service Manual
What is the recommended maximum daily operating time?
The screwdriver should not be used for more than 8 hours per day.
From: Kilews P1L-BSD-3000/3200/3300 Electric Screwdriver Operation Manual
How can I verify that the tool is properly grounded?
Measure the resistance between the power‑line ground and the screwdriver’s metal housing; a reading between 0 Ω and 10 Ω indicates proper grounding.
From: Kilews P1L-BSD-3000/3200/3300 Electric Screwdriver Operation Manual
