Genosys EDR-500A Auto Dropper Service Manual

The EDR-500A is a 96‑channel automatic liquid dispenser that can draw reagents from a reservoir or deep‑well plate and dispense them into 96‑well microplates. It supports both droplet‑type and nozzle‑type dispensing heads, offering high‑precision dispensing from 1 µL up to 300 µL and adjustable suction and ejection speeds.

The device features an LCD display with function keys (F1‑F4) for program editing, parameter changes, and start/stop control. Accessories include interchangeable droplet heads, nozzle heads, a stirring unit, and automatic plate supply mechanisms. Maintenance tasks such as head cleaning, replacement, and calibration are described, and the manual lists all optional parts and consumables. This manual is written in Chinese.

Covers: Technical Specifications · Parameter Settings · Dispensing Modes · Accessories and Parts · Main Unit · LCD Display and Controls
