Featured AWS manuals
AWS Basic Model Temperature Humidity Controller Installation Guide
The AWS Basic Model temperature and humidity controller is designed for use in medium‑high voltage switchgear, terminal boxes, ring‑main units and transformer cabinets. It monitors two temperature and two humidity channels, offers heating and fan cooling, and supports both card‑rail and base mounting styles.
The guide provides detailed installation steps, wiring diagrams for single‑ and dual‑circuit configurations, sensor connection details, and information on power supply, relay contacts, and safety features. It also includes ordering information and after‑sales service contacts. This manual is written in Chinese.
Covers: Overview · Naming · Product Features · Technical Specifications · Installation and Use · Ordering Guide
Latest AWS manuals
AWS Basic Model Temperature Humidity Controller Installation Guide
Installation Guide 7 pages · 238 KB · ZHInstallation guide for the AWS Basic Model temperature and humidity controller, covering setup, wiring, and operation.
AWS BPM Platform Developer Manual AWS Reference Manual
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in AWS manuals
How many temperature and humidity channels can the controller monitor?
It can monitor two temperature channels and two humidity channels, and can also operate with single‑temperature control.
From: AWS Basic Model Temperature Humidity Controller Installation Guide
What installation methods are supported?
The controller can be installed using a card‑rail or base style, and can also be embedded.
From: AWS Basic Model Temperature Humidity Controller Installation Guide
