Featured ASCON manuals
ASCON C1 Thermostat Selection Sample
The ASCON C1 thermostat is a compact controller‑indicator‑transmitter unit (1/32 DIN, 48×24 mm) with simple operation via front‑panel keys or serial communication. It supports configurable input types, control algorithms, output forms, alarm functions and auxiliary features.
Key features include PID or ON‑OFF control loops, multiple alarm indicators, RS485 Modbus/Jbus communication, IP65 front‑panel protection, and flexible power options ranging from 85‑264 VAC to 18‑28 VAC or 20‑30 VDC. This manual is written in Chinese.
Covers: Features · Control Algorithms · Input & Output Specifications · Power Supply · Communication · Alarm Functions
Latest ASCON manuals
ASCON C1 Thermostat Selection Sample
Product Leaflet 1 pages · 116 KB · ZHSelection sample for the ASCON C1 thermostat showing specifications, inputs, outputs and communication options.
Questions answered in ASCON manuals
What is the temperature measurement accuracy?
The device provides an accuracy of 0.25 % for both thermocouple (TC) and RTD inputs.
Which communication protocol does the thermostat support?
It supports RS485 communication using the Modbus/Jbus protocol (optional).
