Featured ARMFLY manuals
Armfly STM32F103ZE-EK Development Board User Manual
This manual introduces the STM32F103ZE‑EK development board, which is built around an STM32F103ZET6 (LQFP144) MCU. It lists the board's extensive hardware resources, including flash, RAM, USB, CAN, timers, peripherals and connectors.
The document guides users through power requirements, hardware testing with the built‑in test program, jumper settings, and recommended learning steps, helping beginners quickly start development and evaluate projects. This manual is written in Chinese.
Covers: Product Specifications · Hardware Resources · Power Supply Requirements · Hardware Test Procedure · Jumpers Configuration · Learning Suggestions
Latest ARMFLY manuals
Armfly STM32F103ZE-EK Development Board User Manual
User Manual 37 pages · 1.1 MB · ZHThe Armfly STM32F103ZE-EK development board user manual provides hardware specs, setup steps and testing procedures.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ARMFLY manuals
What external power voltage is required for the board?
The board must be powered with a 5.0 V DC external supply, with correct polarity (inner positive, outer negative).
How many USB ports does the development board provide?
It provides one USB 2.0 full‑speed device port and one USB 2.0 full‑speed host port.
