Featured adlinktech manuals
ADLINK PXI/DAQ/DAQe Series Selection Guide
The ADLINK PXI/DAQ/DAQe series provides high‑performance, simultaneous‑sampling data acquisition cards for PXI and PCI platforms. The guide lists analog input and output resolutions, channel counts, sampling rates, and I/O features for each model, along with hardware options such as terminal boards and SSI synchronization cables.
Key features include 32‑bit bus‑mastering DMA, auto‑calibration, programmable gains, and support for Windows and Linux operating systems. The document also details ordering numbers, pin assignments, and mechanical dimensions to aid system integration and selection.
Covers: Selection Guide · Introduction · Features · High‑Performance DAQ Specifications · Analog Input · Analog Output
Latest adlinktech manuals
ADLINK PXI/DAQ/DAQe Series Selection Guide
Product Leaflet 56 pages · 2.4 MB · ENSelection guide for ADLINK PXI/DAQ/DAQe data acquisition modules with specifications and ordering information.
Questions answered in adlinktech manuals
Can multiple PXI/DAQ/DAQe cards be synchronized?
Yes, cards can be synchronized through the SSI (System Synchronization Interface) bus.
What is the maximum analog output update rate for the PXI/DAQ/DAQe‑2010?
The analog output can be updated at up to 1 MS/s.
