Featured Actions manuals
Actions ATT7026A Energy Measurement Chip User Manual
The ATT7026A is a high‑precision three‑phase active and reactive energy measurement chip designed for three‑wire and four‑wire power‑meter applications. It integrates six sigma‑delta ADC channels, on‑chip DSP processing and provides active, reactive, apparent power, power factor, phase angle and frequency measurements.
The document covers chip characteristics, pin assignments, system functions such as power‑monitoring and reset, hardware and software calibration procedures, the SPI communication protocol, and detailed electrical parameters and package information. This manual is written in Chinese.
Covers: Chip Introduction · Pin Definition · System Functions · Calibration Methods · SPI Communication Interface · Electrical Characteristics
Actions ATT7022B Chip User Manual
The manual introduces the ATT7022B multifunction anti‑theft energy measurement chip, highlighting its high‑precision capabilities, support for active, reactive, apparent power and harmonic measurements, and suitability for three‑phase three‑wire or four‑wire applications.
It then covers system functions such as power‑monitoring, reset methods, ADC conversion, calibration procedures, the SPI communication interface, and provides detailed electrical parameters and package information. This manual is written in Chinese.
Covers: Chip Introduction · Chip Features · Pin Definitions · System Functions · SPI Communication Interface · Calibration Methods
Latest Actions manuals
Actions ATT7026A Energy Measurement Chip User Manual
User Manual 41 pages · 1.2 MB · ZHThe manual describes the features, pin definitions, system functions, calibration methods, SPI interface and electrical specifications of the ATT7026A…
Actions ATT7022B Chip User Manual
User Manual 49 pages · 1.6 MB · ZHThe Actions ATT7022B chip user manual describes features, pin definitions, system functions, SPI interface, and electrical specifications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Actions manuals
What communication interface does the ATT7026A use?
The chip provides an SPI interface for transferring measurement data and calibration parameters between the ATT7026A and an external MCU.
How can the ATT7026A be calibrated?
Calibration can be performed either with a hardware resistor‑network method or a software method that uses calibration registers to adjust gain and phase.
What is the supply voltage range for the ATT7022B?
The chip operates with a VCC supply voltage between 4.75 V and 5.25 V.
How can the chip be reset via the SPI interface?
A software reset is performed by writing the command 0xD3 to the SPI port, which triggers a reset of the ATT7022B.
