Featured Beijing manuals
Beijing Newview Broadband Communication YA VDT/VDR120 Fiber Optical Link Product Leaflet
The YA VDT/VDR120 series is a single‑mode fiber optical terminal offering one video channel (PAL, NTSC, SECAM) and one control data channel. It supports 10‑bit video, 23 MHz video frequency and provides RS‑485, RS‑232 and TTL interfaces for flexible integration.
Mechanical dimensions are compact (93 mm × 70 mm × 25 mm) with a 5 V DC/700 mA power supply. The device operates from –40 °C to +70 °C, stores up to –40 °C to +85 °C, and has an MTBF exceeding 100 000 hours. Optical performance includes single‑mode 1310 nm/1550 nm wavelengths with up to 120 km transmission distance. This manual is written in Chinese.
Covers: Features · Technical Specifications · Mechanical Characteristics · Related Models
Latest Beijing manuals
Beijing Newview Broadband Communication YA VDT/VDR120 Fiber Optical Link Product Leaflet
Product Leaflet 2 pages · 144 KB · ZHThis leaflet provides specifications, interfaces and installation details for the YA VDT/VDR120 fiber optical link from Beijing Newview Broadband Communication.
Questions answered in Beijing manuals
What video standards does the YA VDT/VDR120 support?
It supports PAL, NTSC and SECAM video standards.
From: Beijing Newview Broadband Communication YA VDT/VDR120 Fiber Optical Link Product Leaflet
What is the maximum transmission distance of the optical link?
The link can reach up to 120 km.
From: Beijing Newview Broadband Communication YA VDT/VDR120 Fiber Optical Link Product Leaflet
