Featured 上海来扬电气科技有限公司 manuals
Shanghai Laiyang Electric Technology LYGC-6800 Gas Chromatograph User Manual
The LYGC-6800 is a power‑specific gas chromatograph designed for transformer oil analysis and other electrical applications. The manual begins with safety information covering high‑voltage, high‑temperature, and gas‑source hazards, and explains the required protective measures before any work on the instrument.
Subsequent sections detail unpacking, installation of gas lines, pressure regulators, and the workstation software, followed by step‑by‑step operating instructions, detector settings, and data‑processing functions. The final chapters cover routine cleaning, component maintenance, and troubleshooting of common faults. This manual is written in Chinese.
Covers: Instrument Introduction · Technical Specifications · Main Configuration · Installation · Operation · Workstation Software
Shanghai Laiyang LYGCXT5000 Oil Chromatography Online Monitoring System User Manual
This user manual provides detailed instructions for safely installing, configuring, and operating the LYGCXT5000 transformer oil chromatography online monitoring system. It covers system components, wiring, sampling procedures, data acquisition, and fault‑diagnosis features.
The document also lists applicable standards, environmental limits, technical parameters, and maintenance guidelines, helping users ensure reliable long‑term monitoring of dissolved gases in high‑voltage transformer oil. This manual is written in Chinese.
Covers: Basic Description · Related Standards · Safety Regulations · System Overview · System Composition · Working Principle
Latest 上海来扬电气科技有限公司 manuals
Shanghai Laiyang Electric Technology LYGC-6800 Gas Chromatograph User Manual
User Manual 120 pages · 2.9 MB · ZHThe LYGC-6800 gas chromatograph manual from Shanghai Laiyang Electric Technology provides safety warnings, installation steps, operation procedures, and…
Shanghai Laiyang LYGCXT5000 Oil Chromatography Online Monitoring System User Manual
User Manual 27 pages · 671 KB · ZHThe manual explains installation, operation, safety and technical specifications of the LYGCXT5000 transformer oil chromatography monitoring system.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 上海来扬电气科技有限公司 manuals
What safety precautions must be taken before opening the instrument?
The instrument contains high voltage that can cause injury, so the power plug must be removed and the power switch turned off before any cover is opened.
From: Shanghai Laiyang Electric Technology LYGC-6800 Gas Chromatograph User Manual
How should the gas source be installed and checked for leaks?
Connect the gas lines, close the gas source valve, then perform a leak test on all connections before opening the hydrogen gas supply.
From: Shanghai Laiyang Electric Technology LYGC-6800 Gas Chromatograph User Manual
What is the minimum detection cycle for the LYGCXT5000 system?
The system can perform a detection cycle as short as 40–60 minutes; the default setting is once every 24 hours.
From: Shanghai Laiyang LYGCXT5000 Oil Chromatography Online Monitoring System User Manual
What power supply does the LYGCXT5000 require?
It operates from an AC 220 V ±10% 50 Hz power source with a consumption of about 1000 W.
From: Shanghai Laiyang LYGCXT5000 Oil Chromatography Online Monitoring System User Manual
