Featured Guangzhou Dacai manuals
Guangzhou Dacai DC10600B070_05XX_RTC Touch Screen Datasheet
The DC10600B070_05XX_RTC is an industrial‑class 7.0‑inch touch screen produced by Guangzhou Dacai. The document details the product’s hardware architecture, available touch technologies (resistive, capacitive or none) and the development tools needed for integration.
Key specifications include a 1024 × 600 pixel resolution, 180 cd/m² brightness, 2000:1 contrast, 55/55/5° viewing angle, power consumption of 694 mA@5 V, and operating temperature range of –20 °C to +70 °C. Supported interfaces are RS232, USB and SD‑card, and the sheet also lists reliability test procedures and mechanical dimensions for system designers. This manual is written in Chinese.
Covers: Hardware Overview · Product Specifications · Dimensions · Reliability Testing · Communication Interfaces · Debugging Tools
Guangzhou Dacai DC12480M068_X111_0X(C/N) Data Sheet
The document introduces the medical‑grade DC12480M068_X111_0X(C/N) touch screen, describing its external appearance, hardware configuration and required debugging tools. It details the product series, core processor, operating system, communication protocols, power requirements and storage capabilities.
It also covers development resources such as the VisualTFT software, virtual serial‑screen simulation, LUA scripting support, Wi‑Fi module options, and provides guidelines for hardware integration, pin assignments, reliability testing and packaging dimensions. This manual is written in Chinese.
Covers: Hardware Introduction · Product Specifications · Product Dimensions · Pin Definition · Reliability Testing · Model Definition
Latest Guangzhou Dacai manuals
Guangzhou Dacai DC10600B070_05XX_RTC Touch Screen Datasheet
Datasheet 18 pages · 3.9 MB · ZHThis datasheet provides specifications, hardware configuration, dimensions, reliability test results and communication interfaces for the…
Guangzhou Dacai DC12480M068_X111_0X(C/N) Data Sheet
Datasheet 25 pages · 5.6 MB · ZHThis datasheet provides specifications, hardware configuration, dimensions, pin definitions, reliability tests, protocol and LUA script settings for the…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Guangzhou Dacai manuals
What is the screen size and resolution of the DC10600B070_05XX_RTC?
The screen measures 7.0 inches and has a resolution of 1024 × 600 pixels.
From: Guangzhou Dacai DC10600B070_05XX_RTC Touch Screen Datasheet
What is the power consumption of the display?
The display draws 694 mA when powered at 5 V.
From: Guangzhou Dacai DC10600B070_05XX_RTC Touch Screen Datasheet
What communication interfaces does the DC12480M068_X111_0X(C/N) touch screen support?
It supports RS232 and TTL levels; the default is RS232 voltage, and shorting J5 switches to TTL.
What is the operating voltage range for the touch screen?
The device operates from 5 V to 30 V.
