Yingda PIO Series Power Inductor Datasheet
The PIO series from Yingda provides a range of surface‑mount power inductors for high‑density applications such as mobile communications, notebook computers, LCD televisions and DC/DC converters. Each part lists inductance, tolerance, DCR, saturation current and mechanical dimensions.
The document includes ordering codes, packaging styles (Tape&Reel or Bulk), and detailed electrical characteristics measured at 100 kHz (or 1 kHz for the KT variants). This information helps designers select the appropriate inductor for their circuit requirements. This manual is written in Chinese.
Covers: Features · Applications · Ordering Code · Dimensions · Electrical Characteristics · Packaging Style
Yingda FHW Series SMD Inductor Datasheet
The FHW series wire‑wound chip inductors are compact SMD components with a terminal electrode structure that reduces parasitic effects and improves solderability. They are offered in various package sizes such as 0402, 0603, 0805, 1008, 1210, and 1812, suitable for high‑density surface‑mount applications.
The datasheet lists detailed specifications including inductance values, tolerance, Q, SRF, DCR, and maximum rated current, together with reliability test results for temperature, humidity, vibration, and solder‑heat resistance. Packaging options include tape‑and‑reel and bulk formats. This manual is written in Chinese.
Covers: Features · Applications · Ordering Code · Dimensions · Electrical Characteristics · Characteristic Curve
Latest Yingda manuals
Yingda PIO Series Power Inductor Datasheet
Datasheet 6 pages · 175 KB · ZHTechnical data sheet for Yingda PIO series surface‑mount power inductors, including dimensions, electrical parameters and packaging options.
Yingda FHW Series SMD Inductor Datasheet
Datasheet 10 pages · 1 MB · ZHThe Yingda FHW series SMD inductor datasheet provides dimensions, electrical characteristics, and reliability test data for multiple package sizes.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Yingda manuals
Which applications are the PIO series inductors suitable for?
They are suitable for mobile communications, notebook computers, LCD televisions and DC/DC converters.
What does Isat represent in the specifications?
Isat is the saturation current, the current at which the inductance drops by 10 %.
What is the operating temperature range of the FHW series inductors?
The operating temperature range is –40 °C to +125 °C.
What is the Q value range for the FHW series?
The Q value ranges from 13 to 65 (minimum).
