Featured Shuguan manuals
Shuguan SLR3066 LED Product Datasheet
The SLR3066 is a 3 mm flat‑top, ultra‑bright red LED (λ=622 nm) designed for security systems, fiber‑optic amplifiers and photo‑switches. It features a lead‑free, environmentally friendly package with a 3.1 mm edge‑flat and 2.54 mm standard pin spacing.
The datasheet provides limit parameters such as a continuous forward current of 70 mA, pulse peak current of 400 mA, reverse voltage of 10 V, and power dissipation of 150 mW. It also lists optoelectronic specs, storage guidelines, and handling precautions including ESD protection and proper lead forming before soldering. This manual is written in Chinese.
Covers: Features · Description · Applications · Dimensions · Limit Parameters · Optoelectronic Parameters
Shuguan SGPT5953C 5mm Darlington Phototransistor Technical Data Sheet
The SGPT5953C is a Darlington phototransistor packaged in a 5 mm flat‑lens plastic case. It offers fast response time, high photo‑sensitivity, and is Pb‑free, meeting RoHS requirements. The device is sensitive to visible and infrared radiation due to its water‑clear epoxy.
Typical applications include infrared detection systems, security systems, road and night lamps, and optoelectronic switches. The datasheet provides absolute maximum ratings, electro‑optical characteristics, and typical performance curves for designers.
Covers: Features · Description · Applications · Absolute Maximum Ratings · Electro‑Optical Characteristics · Typical Performance Curves
Shuguan PD753B Silicon PIN Photodiode Technical Data Sheet
The PD753B silicon PIN photodiode is offered in a black plastic package that also acts as an infrared filter matched to an IR emitter. It features fast response time, high photosensitivity, low junction capacitance and complies with RoHS.
The data sheet lists absolute maximum ratings, electro‑optical characteristics, typical performance curves, packaging details and handling notes, providing all necessary information for designers and integrators. This manual is written in Chinese.
Covers: Features · Descriptions · Applications · Package Dimensions · Absolute Maximum Ratings · Electro‑Optical Characteristics
Latest Shuguan manuals
Shuguan SLR3066 LED Product Datasheet
Datasheet 4 pages · 274 KB · ZHThe SLR3066 is a 3.1 mm edge‑flat, high‑brightness red LED with 622 nm wavelength and detailed electrical and optical specifications.
Shuguan SGPT5953C 5mm Darlington Phototransistor Technical Data Sheet
Datasheet 4 pages · 89 KB · ENThe Shuguan SGPT5953C is a 5 mm Darlington phototransistor with fast response, high sensitivity, and RoHS‑compliant specifications.
Shuguan PD753B Silicon PIN Photodiode Technical Data Sheet
Datasheet 4 pages · 262 KB · ZHThe Shuguan PD753B is a high‑speed, high‑sensitivity silicon PIN photodiode presented in a technical data sheet with full specifications.
