Featured CMNTEK manuals
CMNTEK UR-1000PLUS Series Ultrasonic Flowmeter User Manual
The CMNTEK UR-1000PLUS series is a wetted multi‑path ultrasonic flowmeter designed for accurate measurement of liquid flow in industrial pipelines. It supports a range of pipe sizes and pressure ratings, and offers both analog (4‑20 mA) and pulse outputs.
The manual includes detailed specifications, wiring diagrams, controller functions, keypad/display operation, data logging features, and fault diagnosis procedures. It also describes enclosure ratings, power requirements, and communication options such as RS‑232 and RS‑485.
Covers: Specification · Controller · Enclosure · Output · Ultrasonic Transducer · Wetted Transducers
Latest CMNTEK manuals
CMNTEK UR-1000PLUS Series Ultrasonic Flowmeter User Manual
User Manual 48 pages · 1.7 MB · ENThe CMNTEK UR-1000PLUS series ultrasonic flowmeter user manual provides specifications, installation, operation, and troubleshooting information.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in CMNTEK manuals
What power supply voltage does the flowmeter require?
It operates on 110/220 VAC (50/60 Hz) and consumes 10~15 W.
From: CMNTEK UR-1000PLUS Series Ultrasonic Flowmeter User Manual
Which communication interfaces are supported?
The device supports RS‑232 or RS‑485 communication.
From: CMNTEK UR-1000PLUS Series Ultrasonic Flowmeter User Manual
