Featured Zhongrui manuals
Zhongrui H770 Magnetostrictive Level Meter Quick Start Guide
This guide walks you through the assembly of the H770 magnetostrictive level meter, connecting it to a test system, and configuring key parameters such as float polarity, signal threshold, and range settings. It also covers user calibration procedures and LCD display options.
Additional sections explain fault codes, troubleshooting steps, and detailed button functions, helping users maintain reliable operation of the level gauge in industrial applications. This manual is written in Chinese.
Covers: Assembly of the Magnetostrictive Level Meter · Connecting the Test System · Configuration 1 – Magnetostrictive Parameters · Configuration 2 – Additional Functions · Configuration 3 – Range and Output Settings · User Calibration
Latest Zhongrui manuals
Zhongrui H770 Magnetostrictive Level Meter Quick Start Guide
Quick Start Guide 13 pages · 572 KB · ZHQuick start guide for assembling, configuring, and calibrating the H770 magnetostrictive level meter.
Which document do I need?
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Questions answered in Zhongrui manuals
What communication resistor value is required for the H770?
The power circuit must include a communication resistor of 200 to 500 Ω.
From: Zhongrui H770 Magnetostrictive Level Meter Quick Start Guide
How can I change the variables shown on the LCD screen?
Press the S key to cycle through the variables (current, percentage, main variable, temperature) and release the key when the desired variable appears.
From: Zhongrui H770 Magnetostrictive Level Meter Quick Start Guide
