Key facts
- Manuals
- 2
- Languages
- ZH
- Last added
- 2026-10-03
Featured Fortior manuals
Fortior FD2103C&S Half-Bridge Gate Driver Datasheet
The FD2103C&S half‑bridge gate driver is designed for high‑voltage, high‑speed driving of N‑type power MOSFETs. It includes UVLO protection, built‑in shoot‑through prevention, and a programmable dead‑time of 100 ns.
The datasheet provides absolute maximum ratings, recommended operating conditions, static and dynamic electrical parameters, pin configuration, timing diagrams, and typical application circuits for motor drives and DC‑DC converters. This manual is written in Chinese.
Covers: Overview · Package · Features · Applications · Absolute Maximum Ratings · Recommended Operating Conditions
Fortior FD2606S 600V Half‑Bridge Gate Driver Datasheet
The FD2606S is a high‑voltage, high‑speed half‑bridge gate driver capable of driving N‑type power MOSFETs and IGBTs. It includes built‑in VCC and VB undervoltage (UVLO) protection, TTL/CMOS compatible logic inputs, and a high‑pulse‑current buffer design.
The document provides absolute maximum ratings, recommended operating conditions, electrical parameters, pin configuration, typical application schematics, and package dimensions for designers integrating the driver into motor drives, DC‑DC converters, or DC‑AC inverters. This manual is written in Chinese.
Covers: Overview · Features · Absolute Maximum Ratings · Recommended Operating Conditions · Electrical Parameters · Pin Configuration
Latest Fortior manuals
Fortior FD2103C&S Half-Bridge Gate Driver Datasheet
Datasheet 9 pages · 648 KB · ZHThe FD2103C&S is a 180 V half‑bridge gate driver with UVLO protection, built‑in dead‑time and 3.3 V/5 V logic compatibility.
Fortior FD2606S 600V Half‑Bridge Gate Driver Datasheet
Datasheet 9 pages · 648 KB · ZHTechnical datasheet for the Fortior FD2606S 600 V half‑bridge gate driver with specifications, pinout and typical application circuits.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Fortior manuals
What is the maximum floating absolute voltage of the FD2103C&S?
The device can handle a floating absolute voltage of up to +180 V.
From: Fortior FD2103C&S Half-Bridge Gate Driver Datasheet
What are the high‑level and low‑level input threshold voltages?
The high‑level input threshold (VIH) is 2.7 V and the low‑level input threshold (VIL) is 0.8 V.
From: Fortior FD2103C&S Half-Bridge Gate Driver Datasheet
What is the maximum high‑side voltage the driver can handle?
The absolute maximum high‑side floating voltage is up to 625 V.
From: Fortior FD2606S 600V Half‑Bridge Gate Driver Datasheet
Which logic levels are supported for the inputs?
Inputs are compatible with TTL and CMOS logic, supporting 3.3 V and 5 V levels.
From: Fortior FD2606S 600V Half‑Bridge Gate Driver Datasheet
