Featured Salens manuals
Salens AS083-SS1 PIR Controller IC Datasheet
The AS083-SS1 is a CMOS‑process PIR controller IC designed with mixed‑mode analog and digital circuitry for high stability and low power consumption. It incorporates a high‑precision algorithm unit that self‑adjusts to the environment, filters interference, and can detect human motion at distances of over twenty meters.
Key features include an internal reference voltage for the PIR sensor, built‑in operational amplifiers, a high‑precision crystal, and a programmable timing delay with 12 selectable steps. The chip is supplied in a compact SOP8 package and is suitable for applications such as automatic lighting, security alarms, door‑bell systems, digital cameras, and smart toys. This manual is written in Chinese.
Covers: Function Description · Product Features · Applications · Pin Definitions · Electrical Specifications · Package Dimensions
Salens RDS1000 Radar Light Control Module Specification Sheet
The RDS1000 radar light control module from Salens uses a Doppler‑effect radar chip to detect motion and control lighting in smart‑lighting and IoT applications. It emits high‑frequency electromagnetic waves, processes the reflected signal, and outputs a TTL high‑level signal to switch lights on or off.
Key technical parameters include a 10.525 GHz center frequency, detection distance up to 4–6 m when mounted 3 m high (adjustable 30 cm–12 m), detection angle of 100° ± 10°, operating voltage 5.0–16.0 V DC, current ≤20 mA, and a compact size of 23 mm × 32 mm. Proper power‑supply design and installation away from metal objects are required for reliable operation. This manual is written in Chinese.
Covers: Product Overview · Technical Parameters · Specifications · Application Examples · Power Supply Guidelines · Installation and Usage Notes
Latest Salens manuals
Salens AS083-SS1 PIR Controller IC Datasheet
Datasheet 7 pages · 510 KB · ZHThe Salens AS083-SS1 is a low‑power CMOS PIR controller IC with built‑in amplifier, algorithm unit and adjustable timing for reliable motion detection.
Salens RDS1000 Radar Light Control Module Specification Sheet
Datasheet 4 pages · 625 KB · ZHThe Salens RDS1000 radar light control module specification sheet details its dimensions, operating voltage, detection range, and interface pins.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Salens manuals
What is the typical supply voltage for the AS083-SS1?
The typical supply voltage (VDD) is 3.3 V.
How many timing delay settings does the AS083-SS1 provide?
The timing control input provides 12 selectable delay steps.
