Featured NXP Semiconductors manuals
NXP i.MX 6SoloLite Applications Processor Data Sheet
The i.MX 6SoloLite is an applications processor built around an ARM Cortex‑A9 MPCore CPU that runs at speeds up to 1 GHz and includes integrated graphics, power management, and a range of peripheral interfaces. It targets consumer products such as e‑readers, entry‑level tablets, and barcode scanners.
The datasheet details the processor’s architecture, module list, electrical characteristics, boot mode options, and package information, providing designers with the necessary specifications to integrate the device into their designs.
Covers: Introduction · Features · Architectural Overview · Modules List · Electrical Characteristics · Boot Mode Configuration
NXP Semiconductors BAV170 Low-leakage Double Diode Datasheet
The BAV170 is a low‑leakage double diode offered in a plastic SOT‑23 surface‑mount package. It features a typical leakage current of 3 pA, a switching time of 0.8 µs, and can handle up to 75 V continuous reverse voltage.
The document provides detailed electrical characteristics, thermal ratings, pin configuration, and package dimensions, along with legal notices and contact information for NXP Semiconductors.
Covers: Features · Application · Pinning · Limiting Values · Electrical Characteristics · Thermal Characteristics
Latest NXP Semiconductors manuals
NXP i.MX 6SoloLite Applications Processor Data Sheet
Datasheet 104 pages · 820 KB · ENTechnical data sheet for the NXP i.MX 6SoloLite processor covering features, specifications, and package information.
NXP Semiconductors BAV170 Low-leakage Double Diode Datasheet
Datasheet 10 pages · 306 KB · ENDatasheet for the NXP BAV170 low‑leakage double diode with electrical, thermal and package specifications.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in NXP Semiconductors manuals
What graphics accelerators are integrated in the i.MX 6SoloLite?
The processor includes a 2D graphics unit (GPU2Dv2), an OpenVG 1.1 graphics unit (GPUVG), and a pixel processing pipeline (PXP) for E‑Ink display support.
How many UART interfaces does the processor provide?
The i.MX 6SoloLite includes five UARTs, each capable of up to 5 Mbps.
