Featured Nexperia manuals
Nexperia PDTC144W NPN Resistor-Equipped Transistor Datasheet
The PDTC144W series are NPN transistors with built‑in bias resistors (R1 = 47 kΩ, R2 = 22 kΩ) that simplify circuit design and reduce component count. The document lists electrical limits, thermal characteristics, and mechanical dimensions for each package type.
Key features include built‑in bias resistors, a collector‑emitter voltage rating of 50 V, and a maximum output current of 100 mA. Recommended soldering method is reflow soldering, and the series is suitable for general‑purpose switching, amplification, inverter and interface circuits.
Covers: Features · Applications · Quick Reference Data · Electrical Characteristics · Thermal Characteristics · Package Outlines
Nexperia PBSS5330X PNP Low VCEsat Transistor Datasheet
The PBSS5330X is a PNP transistor offered in a SOT89 (SC‑62) surface‑mount package. It features a low collector‑emitter saturation voltage, high current capability and is intended for power‑management and peripheral‑driver applications such as DC‑DC converters, battery chargers and LED backlighting.
The document provides electrical limits, thermal characteristics, package dimensions and typical performance curves. It also includes ordering information, reference design data and legal notices.
Covers: Features · Applications · Quick Reference Data · Limiting Values · Thermal Characteristics · Electrical Characteristics
Latest Nexperia manuals
Nexperia PDTC144W NPN Resistor-Equipped Transistor Datasheet
Datasheet 15 pages · 417 KB · ENThis datasheet provides specifications, package outlines, and ordering information for Nexperia PDTC144W series NPN resistor‑equipped transistors.
Nexperia PBSS5330X PNP Low VCEsat Transistor Datasheet
Datasheet 13 pages · 417 KB · ENDatasheet for the Nexperia PBSS5330X PNP transistor with low VCEsat, 30 V rating and 3 A collector current.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Nexperia manuals
What are the built‑in bias resistor values?
The transistors have a 47 kΩ resistor (R1) and a 22 kΩ resistor (R2) built in.
From: Nexperia PDTC144W NPN Resistor-Equipped Transistor Datasheet
Which soldering method is recommended for these devices?
Reflow soldering is the only recommended soldering method.
From: Nexperia PDTC144W NPN Resistor-Equipped Transistor Datasheet
What is the maximum collector current for the PBSS5330X?
The transistor can handle a continuous collector current of up to 3 A.
From: Nexperia PBSS5330X PNP Low VCEsat Transistor Datasheet
Which package does the PBSS5330X use?
It is supplied in a SOT89 (SC‑62) surface‑mount package.
From: Nexperia PBSS5330X PNP Low VCEsat Transistor Datasheet
