Featured Maxim Integrated manuals
Maxim Integrated MAX6443-MAX6452 µP Reset Circuits Long Manual Reset Setup Period Datasheet
The MAX6443‑MAX6452 family are low‑current microprocessor supervisor circuits that monitor supply voltages and assert an active‑low RESET output when a voltage drops below a factory‑set threshold. They feature single or dual manual reset inputs with an extended setup period to avoid nuisance resets, and optional immediate‑reset inputs for fast response.
These devices are offered in small SOT‑143, SOT‑23 packages, operate from –40 °C to +85 °C, and are qualified for automotive (AEC‑Q100) and RoHS‑compliant options. Applications include set‑top boxes, consumer electronics, automotive, industrial equipment, and medical devices. Ordering information, package outlines, and pin configurations are provided in the later sections.
Covers: General Description · Electrical Characteristics · Pin Description · Manual Reset Input Options · Applications Information · Ordering Information
Maxim Integrated Interface Product Guide
The document presents a comprehensive overview of Maxim Integrated's interface portfolio, covering UART, RS‑232/RS‑485, SPI, I²C, USB, Bluetooth and related protocols. It includes data‑rate limits, FIFO sizes, supply voltage ranges, ESD protection levels and package options for each device family.
Key sections describe fault protection, high‑voltage isolation, and application examples, helping designers select the appropriate Maxim part for their communication needs.
Covers: UART · RS‑485 / RS‑422 · RS‑232 · SPI · I²C · USB
Latest Maxim Integrated manuals
Maxim Integrated MAX6443-MAX6452 µP Reset Circuits Long Manual Reset Setup Period Datasheet
Datasheet 13 pages · 1.2 MB · ENThe Maxim Integrated MAX6443‑MAX6452 µP reset circuits provide low‑current supervision with single or dual manual reset inputs and extended setup periods.
Maxim Integrated Interface Product Guide
Product Leaflet 11 pages · 2.9 MB · ENThis guide provides specifications and features for Maxim Integrated's interface products such as UART, RS‑485, SPI, I²C and USB.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Maxim Integrated manuals
What is the reset timeout period?
The reset timeout period is 140 ms minimum (typical 210 ms).
From: Maxim Integrated MAX6443-MAX6452 µP Reset Circuits Long Manual Reset Setup Period Datasheet
How many manual reset inputs does the MAX6445 have?
The MAX6445 has two extended manual reset inputs (MR1 and MR2).
From: Maxim Integrated MAX6443-MAX6452 µP Reset Circuits Long Manual Reset Setup Period Datasheet
What is the maximum data rate supported by Maxim's UART devices?
Maxim UART devices such as the MAX3107 support up to 24 Mbps data rates.
What level of ESD protection do Maxim interface products provide?
Most Maxim interface devices include up to 15 kV (HBM) ESD protection.
