Featured decaWave manuals
Decawave DW1000 User Manual v2.10
This manual describes the DW1000 ultra‑wideband transceiver IC, its features, and how to integrate it into a system. It includes an introduction, hardware overview, and detailed information on SPI communication, power modes, and calibration.
The document is organized into sections covering message transmission, information reception, MAC hardware functions, other functions, the full register set, calibration procedures, design‑choice guidelines, and several appendices with IEEE 802.15.4 specifications and reference material. This manual is written in Chinese.
Covers: Introduction · DW1000 Overview · Message Transmission · Information Reception · MAC Hardware Functions · Other Functions
Decawave DW3000 UWB Transceiver Datasheet
The DW3000 is a fully integrated, low‑power Ultra‑Wideband (UWB) transceiver IC that supports IEEE 802.15.4‑2015 and IEEE 802.15.4z. It can be used for two‑way ranging, TDoA and PDoA location schemes with an accuracy of about 10 cm in healthcare, consumer and industrial real‑time location systems.
The datasheet details the IC description, pin assignments for QFN and WLCSP packages, electrical specifications, functional description, power‑management options, application circuits, packaging dimensions and ordering information, plus a glossary of terms.
Covers: IC Description · Pin Configurations and Function Descriptions · Electrical Specifications · Functional Description · Operational States · Powering DW3000
Latest decaWave manuals
Decawave DW1000 User Manual v2.10
User Manual 117 pages · 10.7 MB · ZHThe Decawave DW1000 User Manual (v2.10) provides an overview, operation, programming, and design guidance for the UWB transceiver IC.
Decawave DW3000 UWB Transceiver Datasheet
Datasheet 56 pages · 2.3 MB · ENThe Decawave DW3000 datasheet provides specifications, pin configurations, and electrical characteristics for the UWB transceiver IC.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in decaWave manuals
What host interface does the DW1000 use?
The DW1000 communicates with a host processor via an SPI (Serial Peripheral Interface) bus.
How many RF bands does the DW1000 operate over?
It operates over six RF bands covering the range from 3.5 GHz to 6.5 GHz.
What is the maximum supply voltage for the DW3000?
The maximum supply voltage is 3.6 V for all VDD pins.
Which data rates does the DW3000 support?
It supports data rates of 850 kbps and 6.8 Mbps.
